Product specification

The following data are the international standard data of Foshan Guangshun Electrical Appliance Co., Ltd. If in doubt or product parameter error,Please contact us.

Performance data
Base model	PW120Z24
Rated voltage V	DC 24V
Current @ rated pressureA	6 A
Rated pressure  kPa	62 kPa & -49kPa
Rated flow L/min	Pressure: 23L/min＠62kPa  Vacuum: 20L/min＠-49kPa (3000r/min)
Speed scale r/min	1000-3000
Ambient  ℃	5～40 ℃
Insolution class	B
Motor type	BLDC
Net weight kg	1.4 kg
Restart pressure kPa	0 kPa

Please contact us for more model specification；Parameters could be design to meet your needs.
